CENTAMAX 2400 Natural Rubber Elastic Element (NR) – Resilient Coupling for Heavy-Duty Marine & Industrial Systems
The CENTAMAX 2400 NR elastic element is engineered to perform under high torque loads and severe vibration conditions. Designed for use in large marine drives, generator sets, and industrial equipment, this size ensures stable, backlash-free power transmission, even in harsh, continuous-duty environments. Its rubber-in-shear design provides exceptional damping performance and safeguards your machinery from torsional shocks.
Technical Specifications (CENTAMAX Size 2400 NR / CM-2400)
- Available Shore Hardness: 50, 60, 70
- Nominal Torque (Tₖₙ): 2,000–2,800 Nm (depending on Shore)
- Maximum Torque (Tₖₘₐₓ): 4,000–6,000 Nm (depending on Shore)
- Max Speed (nₘₐₓ): 3,000 rpm
- Temperature Range (NR): –45 °C to +80 °C
- Material: Natural Rubber (NR)
- Flywheel Standard: SAE J620 – typically SAE 14 or SAE 18, depending on engine flywheel
- Design: Black rubber, plug-in element
Applications of CENTAMAX 2400 NR
- Marine Main Drives & Gensets: Dampens torsional loads in propulsion systems and large ship generators
- Power Generation Equipment: Ensures reliable torque delivery in high-output diesel generator installations
- Industrial Machinery: Ideal for crushers, mixers, pumps, and large compressors under fluctuating torque demands
- Heavy Transportation Systems: Absorbs vibration and reduces resonance in rail and off-road vehicles
Why Choose Original CENTAMAX 2400 NR?
- Proven in Demanding Sectors – Built to withstand the rigors of continuous marine and industrial operation
- Engineered for OEM Precision – Developed in collaboration with leading engine and machine manufacturers to guarantee a precise, long-lasting fit
- Always Available – We stock CENTAMAX 2400 NR elements for immediate worldwide delivery
- Minimizes Downtime – OEM rubber delivers consistent performance and outlasts non-original alternatives, reducing replacement frequency and total ownership costs
Keywords
CENTAMAX 2400 coupling element; CM-2400-50; CM-2400-60; CM-2400-70; elastic rubber element size 2400; generator coupling rubber CM-2400; OEM CENTAMAX 2400 part; SAE 14 coupling element
Additional information
| Weight | 14.8 kg |
|---|---|
| Dimensions | 45 × 45 × 20 cm |
| Centamax Shore | 50, 60, 70 |
